Allen & Heath SQ5+

The Allen & Heath SQ5+ is the most compact model in the new SQ+ range, designed for users who want serious professional mixing power in a compact, more portable format. It takes everything that made the original SQ5 so popular — fast workflow, excellent sound quality, flexible routing and a practical layout — and adds a larger 9-inch touchscreen, refined interface, expanded processing capability, RackUltra FX* and next-generation DEEP Add-On capability.

Built around Allen & Heath’s acclaimed 48-input, 96kHz XCVI core, the SQ5+ delivers low-latency digital mixing with the clarity, speed and flexibility required for modern live sound. It is equally at home in a compact church system, school auditorium, live venue, rehearsal room, portable PA rig, livestream setup or production environment where space matters but capability cannot be compromised.

*Note: Rack Ultra FX engines are built-in, however the Ultra effects themselves are available as additional Add-Ons which must be purchased via the Allen & Heath shop online.

• 48 input processing channels
• 96kHz XCVI core with ultra-low latency <0.7ms
• 17 motorised faders
• 16 local XLR mic/line inputs
• 12 local XLR outputs
• 8x customisable SoftKeys
• 9-inch capacitive touchscreen
• 8x RackExtra FX Engines with dedicated send and returns
• 4x RackUltra FX engines with dedicated sends and returns
• 12x mixes, configurable as mono/stereo, aux/group
• 2x 24-channel or 1x 48-channel advanced Automatic Mic Mixer
• Expanded DEEP processing capability
• 128x128 SLink port for Allen & Heath stageboxes and personal monitoring
• I/O expansion slot for optional Dante, MADI, Waves and SLink cards
• USB recording, playback and 32x32 USB audio interface
• 10 configurable users with permissions to restrict operator access
• Optional 19-inch rackmount kit available

The SQ5+ is particularly appealing because it gives you access to the same core SQ+ processing platform as the larger models, but in the smallest frame size. With 16 local XLR inputs, 12 XLR outputs and extensive expansion options via SLink and optional I/O cards, it can start as a compact standalone mixer and grow into a much larger system when required.

We have always loved the SQ5 because it offers a rare balance of professional capability and real-world usability. The SQ5+ keeps that same practical size and familiar workflow, but the larger screen, sharper look and added processing capability make it feel faster, clearer and more capable. For smaller venues, churches, schools and portable systems, it is an excellent way to access the upgraded SQ+ platform without moving to a larger console.
